GE IS200ECTBG1ADE is an exciter contact terminal card belonging to the Mark VI Speedtronic series. The following is a detailed introduction about GE IS200ECTBG1ADE:

Design purpose:

GE IS200ECTBG1ADE is designed as an exciter contact terminal card in the Mark VI Speedtronic series. This is one of the final systems released by GE under the name Speedtronic for steam and gas industry system management.

System flexibility:

Mark VI is a flexible system, which can be used in various applications. It can be designed as simplex or TMR (the third mock examination redundancy) to meet the needs of large and small systems. MKVI is the third Speedtronic system that provides TMR control.

Configuration and features:

The ECTB terminal card has two basic configurations, while the IS200ECTBG1ADE is only used for redundant systems.

The board has six auxiliary contact inputs powered by M1/M2 power supply.

Four additional universal (C-type) relay outputs, which are controlled by nearby connected EMIO boards.

Two trip contact outputs that drive user locking.

Two terminal boards located on one side, with two three position plugs on the surface of the circuit board.

Three d-shell connectors are used to connect cables along a long edge.

Origin and Warranty:

This product is originally from the United States and typically comes with a 365 day warranty.

Working voltage and installation:

The working voltage range is usually 220V-380V.

The installation method is debugging and installation
