GE VMIVME-5565-11000 (also known as GE VME5565) is a high-performance, multifunctional VMEbus board designed specifically for industrial and embedded computing applications. Here is a detailed introduction about this product:
1、 Product Overview
GE VMIVME-5565-11000 is a reflective memory node card with high-speed, low latency, and deterministic data transfer capabilities. It supports data sharing between up to 256 independent systems (nodes) with a transmission rate of up to 170 megabytes per second (when using 64 byte packets). This board card achieves data communication through fiber optic networks and is suitable for application scenarios that require high data transmission speed and real-time performance.
2、 Main characteristics
VMEbus interface: Supports standard VMEbus interfaces for easy integration with VME systems.
High performance data transmission:
Network transmission rate range: 43 megabytes per second (4-byte packets) to 阿170 megabytes per second (64 byte packets).
VME transmission rate: 40 megabytes per second.
Dynamic packet size: 4 to 64 bytes.
Reflective memory: Equipped with 64 megabytes or 128 megabytes of onboard SDRAM reflective memory, providing fast data read access time.
Fiber optic network connection:
Supports multimode and single-mode optical fibers.
The connection with multimode fiber can reach up to 300 meters, and the connection with single-mode fiber can reach up to 10 kilometers.
Node Expansion: Supports up to 256 nodes, making it easy to build large-scale data sharing networks.
Write synchronization: Data written to the memory of a node will be automatically written to the memory of all nodes on the network, achieving data synchronization.
Easy to use fiber optic network: using a 2.12 Gigabit baud serial rate fiber optic network to ensure the stability and reliability of data transmission.
3、 Application Fields
GE VMIVME-5565-11000 is widely used in multiple fields due to its high performance and reliability, including but not limited to:
Aerospace: Used in scenarios such as flight control systems, data acquisition systems, etc. that require extremely high data transmission speed and real-time performance.
Industrial automation: Real time data sharing and monitoring are achieved in industrial automation systems.
Embedded computing: providing high-speed, low latency data transmission solutions for embedded systems.
4、 Product specifications
Interface: VMEbus。
Number of channels: 16 (number of analog input/output channels, depending on configuration).
Analog input/output resolution: 16 bits.
Number I/O: 32 lines.
Working temperature range: The working temperature range given by different data may vary, but it is usually between -40 ℃~+85 ℃ or 0 ℃~70 ℃ (depending on the application scenario and heat dissipation conditions).
Input voltage: 5VDC.
Power consumption: 10W.
Size: 6U VMEbus shape.
Weight: 200g.
5、 Precautions
Compatibility: Before purchasing and using, please ensure that GE VMIVME-5565-11000 is compatible with your VME system.
Heat dissipation: Due to the high performance of this board, it is necessary to pay attention to heat dissipation during use to ensure its stable operation.
Maintenance: Regularly inspect and maintain the board, promptly identify and address potential issues.
