GE IS2020RKPSG3A is an important product produced by General Electric (GE). The following is a detailed introduction to the product:

1、 Product Overview

GE IS2020RKPSG3A is one of the seven major versions of VME rack power supply designed specifically for Mark VI systems. The Mark VI system is one of the latest Speedtronic steam or gas turbine management systems created and released by GE. IS2020RKPSG3A plays a crucial role as a VME rack power supply in this system.

2、 Main characteristics

Rated output power: 400W, capable of meeting the power requirements of Mark VI systems and other industrial automation control systems.

Rated input voltage: 125Vdc, ensuring stable operation of the power module even in the event of input voltage fluctuations.

Output port: It has one status ID output, one remote+28V PSA output, and five additional+28V PSA outputs. These connections are located at the top and bottom of the device, making it easy to connect with external devices or systems.

Front panel design: equipped with toggle switch, which is the only user control on the module. Users can use this toggle switch to reset module faults, facilitating troubleshooting and module maintenance. The panel is also equipped with three LED indicator lights (green, red, and yellow) to indicate the working status and fault information of the module.

Physical structure: Designed for installation on the right side of the VME control and interface rack. The side of the body is designed with multiple metal fins, which serve as heat dissipation components to help the module maintain an appropriate temperature during continuous operation and prevent overheating from affecting module performance.

3、 Application Fields

The IS2020RKPSG3A rack power module is a powerful and well-designed power module suitable for industrial automation and control systems such as Mark VI systems. It provides reliable assurance for the normal operation of industrial equipment by offering stable power output and flexible fault handling mechanisms.

4、 Product advantages

High performance: With a rated output power of 400W, it can meet the power requirements of most industrial automation control systems.

High reliability: Designed with heat dissipation components and fault handling mechanisms to ensure stable operation of the power module in harsh environments.

Easy to maintain: The toggle switch and LED indicator light on the front panel facilitate troubleshooting and module maintenance for users.

Flexible connection: Multiple output ports and convenient connection methods for easy connection with external devices or systems.
