GE D20 EME 2400-21004 is an industrial automation system spare part provided by GE (General Electric). The following is a detailed introduction to the product:

1、 Product Overview

GE D20 EME 2400-21004 is a high-performance power module or chassis rack designed specifically for industrial automation and control systems, integrating GE's advanced technology in the field of industrial automation. It has stable and reliable power output and powerful system functions, which can meet the power and communication needs of various devices in industrial automation systems.

2、 Main functions and features

Power function:

Provide stable 24V DC power output with a wide input voltage range (such as 8V DC to 35V DC), able to adapt to different input voltage conditions.

The output current can reach 2A, which can meet the current requirements of various equipment in industrial automation systems.

High efficiency (up to 90%) and low ripple noise ensure stable operation of the equipment.

Chassis rack design:

Adopting a sturdy chassis rack structure ensures the stability and durability of the product.

Easy to install and maintain, supporting integration and expansion of various industrial automation components.

Communication and Control:

Supports PLC operating system with powerful communication and control capabilities.

It can achieve tasks such as data collection, communication, automation control, protection, and alarm processing.

High security and reliability:

Compliant with UL 508 certification and suitable for use in hazardous areas.

Provide protection functions such as overvoltage, overcurrent, and short circuit to ensure the safety of equipment and systems.

Environmental adaptability:

Wide working temperature range (-40 ° C to+70 ° C), suitable for different working environments.

High protection level (such as IP67), with dustproof and waterproof functions.

3、 Technical specifications

The main technical specifications of GE D20 EME 2400-21004 include:

Input voltage: 8V DC to 35V DC

Output voltage: 24V DC

Output current: 2A

Power: 48W

Efficiency: up to 90%

Ripple and noise:< 50mVpp

Working temperature range:- 40 ° C to+70 ° C

Protection level: IP67

Size: 102mm x 61mm x 23mm

Weight: 250g

4、 Application Fields

GE D20 EME 2400-21004 is widely used in various industrial automation fields, such as:

Power substation: used to provide stable power supply for equipment in the substation, ensuring the normal operation of the power system.

Distribution station and power grid monitoring: used for power supply to distribution stations and communication and control of power grid monitoring systems.

Power plant: an automated control system used in power plants to improve power generation efficiency and safety.

Industrial sector: such as manufacturing, petrochemicals, metallurgy and other industries, used for power supply, communication and control of various industrial automation equipment.

5、 Precautions

When using GE D20 EME 2400-21004, please ensure that the input voltage and output voltage meet the product specifications.

Do not use this product in environments beyond the working temperature range and protection level.

Please follow the instructions in the product manual during installation and maintenance to ensure the correct installation and stable operation of the product.
