The GE DS200DCFBG1BLC is a power module produced by General Electric (GE). The following is a detailed introduction to the product:

1、 Basic Information

Brand: General Electric (GE)

model: DS200DCFBG1BLC

Type: Power module

2、 Main purpose

The DS200DCFBG1BLC power module is commonly used in industrial control systems and power equipment to provide stable and reliable power supply for the system. It can also be used as a DC filter for various power system applications, including data centers, power transmission systems, renewable energy systems, and industrial control.

3、 Technical specifications

Input/output voltage: It has a specified input voltage range and output voltage to adapt to different power requirements. The rated value of the source AC input is 38 to 115VAC, with a frequency range of 0 to 500kHz depending on the strength of the input voltage.

Rated DC voltage/current: 250V DC, 100A

Filtering efficiency: up to 99%

Impedance: ≤ 1mΩ

Rated power: 25kW

Working temperature: -40 to 85 ° C (-40 to 185 ° F)

Storage temperature: -55 to 90 ° C (-67 to 194 ° F)

Humidity: 5% to 95% non condensing

Protection level: IP67

Size: 400mm x 250mm x 150mm (15.75in x 9.84in x 5.91in)

Weight: 10kg (22.05lb)

4、 Functional Features

High efficiency and stability: Adopting high-efficiency power conversion technology, it has high energy conversion efficiency and stability, ensuring stable power output.

Multiple protection functions: It has multiple protection functions such as overcurrent protection, overvoltage protection, overload protection, etc., to ensure the safe operation of the system and equipment.

Reliability and replaceability: The design features high reliability and long lifespan, as well as hot swappable and hot backup functions, making maintenance and replacement convenient.

Communication Interface: Supports communication interfaces, allowing for data exchange and communication with other devices or systems.

Software support: Equipped with corresponding monitoring and management software, it can achieve remote monitoring and control of the power module.

5、 Application Fields

The DS200DCFBG1BLC power module is widely used in industrial automation, control systems, data centers, power transmission systems, renewable energy systems, and other fields, providing stable and reliable power supply for equipment and systems in these areas.

6、 Compatibility

This power module is a power board designed by General Electric for Mark V series optional and replacement boards, and is cross compatible with many GE brand exciters and drivers, such as DC2000, AC2000, CB2000, ME2000, and FC2000 drivers, all of which can accept this power board.

7、 Additional features

Contains many complex circuit systems designed to power most drivers, such as AC/DC monitoring circuits, control level power circuits, motor excitation power circuits, and drive circuits.

Users can configure jumpers and dip switches on the card to meet any external needs.

The onboard status is conveyed to the user through onboard indicator lights, which are equipped with two LEDs and a neon light to provide important diagnostic and status information for the user.
