Within 3 days after paymentGE DS200FSAAG2ABA is a field power amplifier board or electrical display/keyboard interface board produced by GE (General Electric). The following is a detailed introduction to the product:
1、 Basic Information
Brand: GE (General Electric)
model: DS200FSAAG2ABA
2、 Product Features
Structural composition:
The DS200FSAAG2ABA consists of 36 fence style terminals and provides backplane communication and on-site wiring for input and output modules.
Equipped with latch holes to secure the module in the bracket and transparent hinged doors to provide coverage for the wiring terminals.
Each input/output module comes with printed circuit card labels that can be stacked and integrated into a hinged door.
Connection function:
It has 5 jumpers, a 10 pin connector, and two fuses, as well as multiple testing points.
In addition to the 10 pin connector, it is also equipped with four 2-pin connectors, allowing it to connect to multiple cables.
When disconnecting and reconnecting cables during the replacement process, to avoid prolonged drive downtime, it is recommended to write the identifier of the connector to which the cable is connected on tape and stick it on the cable for reconnection.
Configuration and Protection:
Use an efficient Super scalar RISC CPU.
It has Ethernet co processing function, allowing Ethernet communication modules to be inserted into slots E1 and E2 simultaneously.
Implement write protection for the main memory RAM and backup battery protection in case of power failure, which can quickly restart the original configuration after the main power failure.
Hardware configuration and diagnostic data are stored in a serial 16Kbits EEPROM, while software version information is stored in Flash EPROM, supporting software version upgrades without the need for hardware replacement.
Indicator lights and monitoring functions:
The LED indicator on the power module indicates the working status of the CPU.
The backup protection battery for RAM is placed on the Ethernet module.
Monitor the internal temperature of the CPU board and module, and indicate whether it exceeds the upper limit with LED lights.
Calculate the normal operating time and over temperature operating time of the module.
Power supply and insurance:
The input voltage range is 115~230 VAC, with an allowable range of 90~260 VAC.
The operating frequency is 50-60 Hz, with an allowable range of 47-63 Hz.
The insurance is a glass insurance, 2.5 AT, connected to the input terminal.
Output characteristics:
The output voltage is 3.3 VDC (± 3%) and 5.0 VDC (± 3%).
The output current is 0.5~5 A.
The maximum output power is 26.5 W.
3、 Application and compatibility
DS200FSAAG2ABA, as the VersaMax series barrier type I/O carrier produced by GE Fanuc, is widely used in the field of industrial automation, providing precise control and monitoring functions for various industrial equipment.
This module has good compatibility with other GE products and can be easily integrated into existing control systems.
4、 Maintenance and troubleshooting
When using DS200FSAAG2ABA, regular maintenance and inspection should be carried out to ensure its normal operation.
If a malfunction occurs, refer to the troubleshooting guide in the product manual for troubleshooting and handling.
