GE IS420UCSBH4A is a controller module manufactured by General Electric (GE) and is part of the Mark VIe series. The following is a detailed introduction about the product:

1、 Basic parameters

Model: IS420UCSBH4A

Manufacturer: General Electric (GE)

Manufacturing country/region: United States

Series: Mark VIe

2、 Core functions

Processor: Equipped with a 1066 MHz Intel EP80579 microprocessor, but some information mentions a microprocessor frequency of 600 MHz, which may be a subtle difference between different batches or configurations.

Memory: 256 MB DDR2 SDRAM

Operating System: QNX Neutrino, a real-time multitasking operating system developed specifically for industrial applications that require extremely high speed and reliability.

Application Execution: Application code is executed by an independent computer called the UCSB controller.

3、 Communication and Connection

Interface: Through the onboard IONet (Input/Output Network) interface, the controller can be installed in the panel and communicate with the I/O pack. IONet is a dedicated Ethernet network that provides support for Mark control I/O modules and controllers.

Data synchronization and transmission: Using IEEE 1 protocol, synchronize 1588/O packets and controller clocks through R, S, and T IONet within 100 microseconds. External data is sent to the control system database in the controller through IONet, and data is received from it, including process inputs and outputs of I/O modules.

4、 Characteristics and advantages

High performance: Using high-performance microprocessors and advanced control technology to ensure system stability and response speed.

High reliability: The hardware and software architecture ensures that a single point of application input is not lost when the controller is rejected for maintenance or repair. In addition, the controller has IEC 61508 certification and is specifically configured for use with safety controllers and distributed I/O modules.

Easy to use: Modular design, easy to install and operate. The UCSB controller has a single module built-in power supply, no need for jumper settings, no battery and no fan (such as UCSBSIA, UCSBHIA, UCSBH4A), and has a smaller panel footprint.

Easy to maintain: Provides a simple interface and intelligent diagnostic function, making it convenient for users to troubleshoot and maintain. Flash memory can be easily updated.

5、 Application scope

Industrial field: The IS420UCSBH4A controller module is widely used in industrial fields such as chemical, oil and gas, power, pharmaceutical, food and beverage.

Control system: This module can be integrated with various automation equipment and control systems to achieve efficient and reliable industrial automation and process control.

6、 Other information

Working environment: IS420UCSBH4A has anti vibration and anti electromagnetic interference capabilities, and can operate stably in various industrial environments, ensuring the reliability and stability of the equipment.

LED indicator: The LED indicator lights on the controller can provide visual feedback on the guidance process, error status, and other important information.
