GE IS200ECTBG1ADE is an important industrial control component. The following is a detailed introduction to the product:

1、 Product Overview

Brand and Model: GE brand, model IS200ECTBG1ADE.

Application area: Designed as an excitation machine contact terminal card in the Mark VI Speedtronic series, it is one of the final systems released by GE for steam and gas industry system management.

2、 Product Features

Configuration and compatibility:

There are two basic configurations for ECTB terminal cards, while IS200ECTBG1ADE is only used for redundant systems.

If running a simplex system, reference should be made to the ECTBG2 board.

Compatible with Mark VI Speedtronic series systems.

Input/output characteristics:

It has six auxiliary contact inputs, which are powered by M1/M2 power supply.

Equipped with four additional universal (C-type) relay outputs, the C-type outputs are controlled by nearby EMIO boards.

Provide two trip contact outputs that drive user locking.

Physical characteristics:

This board has two terminal boards located on one side.

The surface of the circuit board is equipped with two three position plugs.

Has three d-shell connectors for connecting cables along one long edge.

The two long sides of the board are processed into a certain shape (engraved with grooves).

3、 Application and Function

Application environment: Suitable for industrial control environments that require high precision and reliability.

Function description: As an excitation machine contact terminal card, IS200ECTBG1ADE plays a key role in control and signal transmission in the system, ensuring stable operation of the system.
